Product overview



Solar street lights integrate LED lighting, solar panels, battery storage and lighting controls for outdoor areas without a direct grid connection at the installation point.


For project buyers, product selection depends on lighting requirements, daily operating hours, local sunlight conditions, installation height and battery capacity. The complete system configuration should be evaluated rather than LED power alone.


First 123 Last

Key specifications

Reference model: XT1958SELD150-SC



Specification

Technical data

LED power

150 W

LED quantity

40 × 5050 LEDs

LED modules

3

Solar panel

Monocrystalline silicon, 36 V / 180 W

Battery

LiFePO₄, 25.6 V / 45 Ah

Battery energy

1,152 Wh

Luminous flux

18,000–21,000 lm

Color temperature

3,000–6,500 K

Color rendering index (CRI)

Ra 70

Full-power lighting duration

12 h

Smart power control duration

84 h

Protection rating

IP66

Beam angle

C0–180°: 150°; T90–270°: 80°

Pole diameter

Ø89 mm

Recommended installation height

10–12 m

Recommended installation spacing

30–36 m

Product dimensions

1,958 × 548 × 86 mm

Net weight

40 kg ± 5%



The lighting duration depends on the operating mode and specified test conditions. Confirm the applicable conditions before using these figures for project design.



Installation and lighting requirements



Site layout:

Confirm road width, pole spacing, mounting height and required illumination before selecting a model.

01

Solar charging conditions:

Assess local sunlight, seasonal variation and potential shading to determine whether the solar panel and battery configuration suit the operating schedule.

02

Environmental conditions:

Check the required ingress protection, temperature range, moisture exposure, dust and corrosion risks against the documented product specifications.

03

Installation compatibility:

Confirm pole diameter, mounting brackets, fixing dimensions, foundation requirements and maintenance access before ordering.

04



Project applications

Smart all in one solar street light


Road and street lighting:

Urban streets, residential roads and rural routes where grid-independent lighting is required.





Parking lots and access roads:

Outdoor parking areas, entrances and internal roads, with configuration based on coverage and operating hours.

Self-maintaining solar street light
Auto Cleaning Solar Street Light


Industrial and commercial premises:

Outdoor circulation routes, entrances and access areas, subject to site conditions and documented product specifications.



Public infrastructure:

Municipal roads, community projects and remote locations, subject to project specifications and local compliance requirements.

Desert-proof Solar Street Light



Customization options

Available options depend on the selected model and confirmed manufacturing capabilities.


Lighting configuration:

LED power, light output, color temperature and lighting control options.


Solar power system:

Solar panel configuration, battery type and battery capacity.

Mounting configuration:

Pole interface, mounting brackets and installation dimensions.

Product identification and packaging:

Product labels, packaging and project documentation, subject to order requirements.

OEM/ODM requirements:

Logo, product modifications and packaging customization, subject to feasibility, minimum order quantity and approval of final specifications.



Manufacturing and quality control



For bulk and project orders, confirm that the supplier can maintain the approved product configuration and provide relevant inspection records.



Component verification:

Check that the LED, solar panel, battery and controller match the approved specifications.




Assembly and inspection:

Confirm which electrical, functional and finished-product checks are performed and documented.




Order consistency:

Align the approved sample, technical specifications, component list, labeling and inspection criteria before mass production.




Documentation:

Request the applicable datasheet, installation instructions, inspection records and compliance documents for the selected model.






Ordering information

To obtain a suitable quotation, provide the following details:

Project requirements:

Application, installation location, quantity and required lighting schedule.

Installation details:

Pole height, spacing, mounting interface and site layout.

Environmental conditions:

Local sunlight, seasonal conditions, temperature and exposure to dust or moisture.

Commercial requirements:

Target delivery schedule, packaging, labeling, documentation and customization requirements.



Before placing an order, confirm the model number, complete system configuration, included accessories, inspection requirements, applicable documents and commercial terms.





FAQ





Q: How do I choose the right solar street light?

A: Start with the road layout, required illumination, mounting height, operating hours and local sunlight conditions. Then compare the LED output, solar panel and battery configuration for the intended application.

Q: Can a solar street light operate during cloudy weather?

A: It can use energy stored in the battery, provided sufficient charge is available. Operating duration depends on previous charging, battery capacity, power consumption and lighting control settings.

Q: How many hours can a solar street light operate?

A: Operating duration varies by model and operating mode. Check whether the published figure refers to full-power operation, dimming or smart power control, and confirm the associated test conditions.

Q: How should I assess battery capacity?

A: Consider the lighting load, required operating hours, control settings and local solar charging conditions. The battery and solar panel should be evaluated as part of the complete system.

Q: Can solar street lights be customized for projects?

A: Some models may support changes to lighting configuration, solar power components, mounting interfaces, labels or packaging. Confirm available options, minimum order quantities and feasibility before ordering.

Q: What documents should I request from a supplier?

A: Request the model-specific datasheet, confirmed component configuration, applicable certificates, relevant test or inspection records and installation instructions.

Q: What information is needed for a bulk quotation?

A: Provide the project location, quantity, application, installation layout, required lighting schedule, environmental conditions and any customization or documentation requirements.

Yantai Xutai New Energy Technology Co., Ltd. is one of the most professional solar street light manufacturers and suppliers in China. With a professional production team, we are able to meet the needs of the majority of our customers. Please rest assured to buy premium solar street light made in China here from our factory.
